Aluminium 6063 | Aluminium He9

Aluminium alloy 6063

Aluminium 6063 | Aluminium He9 is an alloy, with magnesium and silicon as the alloying elements. Aluminium 6063 | Aluminium He9 is a medium quality alloy regularly alluded to as a design alloy. It is ordinarily utilized as a part of multifaceted expulsions.
It has a decent surface completion, high erosion resistance, is promptly suited to welding and can be effortlessly anodised. Most regularly accessible as T6 temper, in the T4 condition it has great formability. Typically used for the applications like architectural applications, extrusions, window frames and doors etc.

CHEMICAL COMPOSITION OF ALUMINIUM ALLOY

Specifications of Aluminium 6063 | Aluminium He9:

  • STM B210
  • ASTM B221
  • ASTM B241
  • ASTM B345
  • ASTM B361
  • ASTM B429
  • ASTM B483
  • ASTM B491
  • UNS A96063
  • Chemical Composition :


    Chemical Element % Present
    Manganese (Mn) 0.0 - 0.10
    Iron (Fe) 0.0 - 0.35
    Magnesium (Mg) 0.45 - 0.90
    Silicon (Si) 0.20 - 0.60
    Zinc (Zn) 0.0 - 0.10
    Titanium (Ti) 0.0 - 0.10
    Chromium (Cr) 0.0 - 0.10
    Copper (Cu) 0.0 - 0.10
    Other (Each) 0.0 - 0.05
    Others (Total) 0.0 - 0.15
    Aluminium (Al) Balance

    Mechanical Properties:


    Property Value
    Tensile Strength 130 Max MPa
    Elongation A50 mm 16 Min %
    Hardness Brinell 25 HB
    Elongation A 18 Min %

    Physical Properties:


    Physical Property Value
    Density 2.70 g/cm³
    Melting Point 655 °C
    Thermal Expansion 23.5 x10^-6 /K
    Modulus of Elasticity 69.5 GPa
    Thermal Conductivity 201 W/m.K
    Electrical Resistivity 0.033 x10^-6 Ω .m
    Electrical Resistivity 52 % IACS
